Colours
41mm
Matte Black Aluminium Case / Obsidian Active Band (2nd gen)
Polished Silver Aluminium Case / Fog Active Band (2nd gen)
Satin Pyrite Aluminium Case / Olive Active Band (2nd gen)
Champagne Gold Aluminium Case / Canyon Active Band (2nd gen)
45mm
Matte Black Aluminium Case / Obsidian Active Band (2nd gen)
Polished Silver Aluminium Case / Fog Active Band (2nd gen)
Satin Pyrite Aluminium Case / Olive Active Band (2nd gen)
Materials and Finishes
Housing: 100% recycled aluminium1
Active Band (2nd gen)
Band made of Hydrogenated Nitrile Butadiene Rubber (HNBR) with soft-touch coating
Dimensions and Weight
41mm
Diameter: 41 mm, Height: 12.3 mm, Weight: 31 g (without band)
45mm
Diameter: 45 mm, Height: 12.3 mm, Weight: 36.7 g (without band)
Display
Actua 360 display
Custom 3D Corning® Gorilla® Glass 5
320 ppi AMOLED LTPO display with DCI-P3 colour
Up to 3,000 nits (peak brightness)
1 nit minimum brightness (AOD)
Responsive display (1–60 Hz)5
Always-on display
Connectivity
Bluetooth® 6.0
Wi-Fi 802.11a/b/g/n/ac/ax 2.4GHz, 5GHz
NFC
Ultra-Wideband
GPS
Dual Frequency GPS: GPS, Galileo, Glonass, Beidou, QZSS
Compatibility
Works with most phones running on Android 12.0 or newer
Requires a Google Account and the Google Pixel Watch app. For more help or information on compatibility, visit g.co/pixelwatch/setup
Band Size
41mm
Active Band: Small and large band sizes included
Small fits wrists 130–175 mm around
Large fits wrists 165–210 mm around
45mm
Active Band: Small and large band sizes included
Small fits wrists 150–185 mm around
Large fits wrists 165–215 mm around
Power (Battery and Charging)
41mm
332 mAh (typical)
Built-in rechargeable lithium-ion battery
Up to 30 hours with always-on display
Up to 48 hours with Battery Saver mode
Quick Charge Dock
Charging speed: About 15 minutes to 50%, About 25 minutes to 80%7, About 45 minutes to 100%
45mm
465 mAh (typical)
Built-in rechargeable lithium-ion battery
Up to 40 hours with always-on display
Up to 72 hours with Battery Saver Mode
Quick Charge Dock
Charging speed: About 15 minutes to 50%, About 30 minutes to 80%, About 60 minutes to 100%
Chip
Qualcomm Snapdragon® W5 Gen 2 Accelerated
Cortex-M55 coprocessor
OS
Wear OS 7.0
Sensors
Compass
Altimeter
Red and infrared sensors for oxygen saturation (SpO2) monitoring
Multipurpose electrical sensors compatible with ECG app
Multi-path optical heart rate sensor
3-axis accelerometer
Gyroscope
Ambient light sensor
Electrical sensor to measure skin conductance (cEDA) for body response tracking
Far-field skin temperature sensor
Barometer
Magnetometer
Interaction
Touchless one-handed gestures
Side button
Haptic crown
Gen 3 Premium haptics
Audio
Built-in microphone
Built-in speaker
Durability and Water Resistance
Custom 3D Corning® Gorilla® Glass 5
5 ATM
IP68
Sustainability
41mm
Google Pixel Watch 5 is made with recycled plastic, cobalt, aluminum, steel, glass, tin, tungsten, gold, copper and rare-earth elements
Housing includes 3% of recycled aluminum
Main logic board is made with 100% recycled copper and gold
Battery cell is made with 100% recycled cobalt
Recycled cobalt is at least 16% of the battery cell weight
Haptic engine is made with 100% recycled tungsten and 100% recycled copper wire
All magnets include 100% recycled rare-earth elements:
Google Pixel Watch 5 uses 100% recycled tin in the solder paste of multiple printed circuit boards, including the main logic board
Packaging for the Google Pixel Watch 5 uses 100% plastic-free materials
45mm
Google Pixel Watch 5 is made with 11% of recycled plastic, metals, glass and rare-earth elements
Housing includes 3% of recycled aluminum
Main logic board is made with 100% recycled copper and gold
Battery cell is made with 16% of recycled cobalt
Haptic engine is made with 100% recycled tungsten and 100% recycled copper wire and other materials
All magnets include 100% recycled rare-earth elements:
100% recycled tin in the solder paste of multiple printed circuit boards, including the main logic board
Packaging for the Google Pixel Watch 5 uses 100% plastic-free materials
What's in the box
Google Pixel Watch 5
Active Band 2nd gen (small and large bands)
Google Pixel Watch Quick Charge Dock
Quick Start Guide
Warranty
12 Months
***Contact us for 4G LTE version
