Technical Information
Diagonal Viewing Size: 23.8"
Preset Display Area (H x V): 527.04 mm x 296.46 mm (20.75" x 11.67"), Area: 156,246.28 mm2 (242.18 inches2)
Panel Type: In-Plane Switching (IPS) technology
Display Screen Coating: Anti-glare with 3H hardness
Maximum Preset Resolution: 1920 x 1080
Refresh rate: 100 Hz
Viewing Angle: 178° vertical / 178° horizontal
Pixel Pitch: 0.2745 mm x 0.2745 mm
Pixel Per Inch (PPI): 92.53
Contrast Ratio: 1,500: 1 (typical)
Aspect Ratio: 16:9
Backlight Technology: LED edgelight system
Brightness: 250 cd/m2 (typical)
Response Time: 5ms gray-to-gray (Fast mode), 8ms gray-to-gray (Normal mode)
Color Support: Up to 16.7 million colors
Color Gamut: 99% sRGB
TÜV Eye Comfort: Yes, 4-Star
Ficker Free: Yes
Connectivity:
1x HDMI 1.4 (HDCP 1.4) (Supports up to FHD 1920 x 1080 100Hz TMDS as per specified in HDMI 1.4)
1x DP 1.4 (HDCP 1.4)
1x DP-out (1.4) with MST (HDCP 1.4)
1x RJ45 Ethernet port, 1GbE
1x USB 3.2 Gen1 Type-C upstream (Alt. mode with DP1.4) with up to 90W PD
3x USB 3.2 Gen1 Type-A downstream
1x USB 3.2 Gen1 Type-C downstream with up to 15W PD (data only)
Built-in Speaker: No
USB Power Delivery: Yes, up to 90W via USB-C upstream (Alt. mode with DP1.4) port, and up to 15W via USB-C downstream port
Adjustability: Height, Tilt, Swivel, Pivot
Height: Up to 150 mm (5.9")
Tilt: -5°/+21°
Swivel: -45°/+45°
Pivot: -90°/+90°
Daisy Chain Availability: Yes
Dell Power Button Sync: Yes, via USB Type-C upstream port
Dell Display Manager Compatibility: Yes with Easy Arrange
Remote Asset Management: Yes
Voltage Required: 100 VAC to 240 VAC / 50 Hz or 60 Hz ± 3 Hz / 2 A (typ)
Power Consumption (Operational) (typical): 0.3 W (Off mode), 0.3 W (Standby mode), 1.0 W (Networked Standby mode), 13.9 W (On mode), 180 W (Max), 15.2 W (Pon), 49.8 kWh (TEC)
Audio Output: Optional soundbar (sold separately)
Security: Security-lock slot (based on Kensington Security Slot™)
Compliant Standards: ENERGY STAR certified monitor, EPEAT GOLD, EPEAT Climate+, TCO Certified Displays, TCO Certified Edge, RoHS-compliant, BFR / PVC free monitor (excluding external cables), Arsenic-free glass and mercury-free (panel only)
Flat Panel Mount Interface: VESA (100 mm x 100mm)
Temperature Range: Operating: 0°C ~ 40°C (32°F ~ 104°F), Non-operating: -20° ~ 60°C (-4° ~ 140°F)
Humidity Range: Operating: 10% ~ 80% (non-condensing), Non-operating: 5% ~ 90% (non-condensing)
Altitude: Operating: 5,000 m (16,404 ft) max, Non-operating: 12,192 m (40,000 ft) max
What's Included: 1x Monitor panel, 1x Stand riser and base, 1x Cable tie, 1x Quick setup guide, 1x Safety, Environmental, and Regulatory Information
Cables Included: 1x Power cord, 1x DP-to-DP cable, 1.8m, 1x USB 3.2 Gen2 Type C-to-C cable, 1.0m
Physical Characteristics
Height with stand (Compressed ~ Extended): 14.33" ~ 19.55"
Width with stand: 21.21"
Depth with stand: 7.16"
Height without stand: 12.37"
Width without stand: 21.21"
Depth without stand: 1.97"
Weight (panel only - for VESA mount): 8.13 lbs
Weight (with packaging): 15.96 lbs
Warranty: 3 Years
